CPU |
- LGA1151 socket 9th/8th Gen Intel® Core™ i7/i5/i3, Pentium® & Celeron® processor (TDP 35W)
|
Chipset |
|
System Memory |
- 1 x 260-pin DDR4-2666 SO-DIMM, up to 16GB
|
BIOS |
|
COM |
|
USB |
|
Ethernet |
- 1 x 10/100/1000 Mbps Ethernet (Intel® I210-AT)
- 1 x 10/100/1000 Mbps Ethernet ( Intel® i219-LM)
- 1 x 10/100/1000 Mbps Ethernet (Intel® I210-AT; optional)
|
Display |
- 1 x HDMI
- 1 x LVDS; 18/24-bit single/dual channel
- 1 x DisplayPort
|
Digital I/O |
- 8-channel in/out programmed
|
Audio |
|
Storage |
- 2 x SATA-600
- 1 x mSATA (optional)
|
Expansion |
- 1 x PCI Express Mini Card slot
- 1 x USB, 1 x PCIe x1, 1 x LPC, 1 x SMBus through a ZIO connector
|
Others |
|
Battery |
|
Power Input |
- 2 x 2-pin connector
- +12V DC-in only
- AT Auto Power On function supported
|
Power Requirements |
|
Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
Hardware Monitoring |
|
Operating Temperature |
- -20°C to +60°C (-4°F to 140°F)
|
Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
Dimensions |
|
Board Thickness |
|
Certifications |
|
Industrial Chassis |
|
