| CPU |
- Intel® Core™ i5-1335UE processor and Intel® processor U300E
|
| Chipset |
|
| System Memory |
- Dual DDR5-5200 SO-DIMM, up to 96GB
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 1G LAN (Intel® I219LM)
- 1 x 2.5GbE LAN (Intel® I226-V)
|
| Display |
- 4 x HDMI 2.1 (TMDS), with cable lock design
|
| Audio |
|
| Storage |
- 1 x M.2 Key M 2280 slot (SATA & NVMe)
|
| Expansion |
- 1 x M.2 Key E 2230 for Wi-Fi/BT, support Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E (CNVi)
- 1 x M.2 Key B 3042/3052 for 3G/4G/5G
- 1 x SIM slot
|
| Others |
|
| TPM |
|
| Power Supply |
|
| Vibration Endurance |
|
| Operating Temperature |
- 0°C to +50°C (+32°F to +122°F) disabling CPU Turbo Boost (with W.T. DRAM & SSD, CPU TDP 15W)
|
Dimensions
(W x D x H) |
- 200 x 165 x 40 mm ( 7.87" x 6.50" x 1.57")
|
| Weight (net/gross) |
- 1.57 kg (3.46 lbs)/2.5 kg (5.51 lbs)
|
| Mounting |
|
| EOS Support |
|
| Software Support |
|
| Certifications |
|
