| LCD Panel |
- 10.4" XGA TFT LCD
- 350 nits
- 1024 x 768 pixels
|
| CPU |
- Intel® Celeron® processor N3350, up to 2.4GHz
- Intel® Pentium® processor N4200, up to 2.5GHz
|
| Chipset |
|
| System Memory |
- 1 x 204-pin SO-DIMM DDR3L-1600, up to 8GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 (default RS-232)
- 1 x RS-232
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet
|
| Display |
|
| Audio |
|
| Storage |
- 1 x 2.5" SATA HDD (9.5 mm height)
- 1 x mSATA
|
| Expansion |
- 1 x Full-size PCI Express Mini Card slot with mSATA
- 1 x Full-size PCI Express Mini Card slot with SIM
|
| Others |
- 1 x Screw type connector for power
- 1 x Power button (ATX)
- 1 x Remote power switch
- 1 x ATX/AT selectable switch
|
| Touchscreen |
- Projected capacitive multi-touch
- 5-wire flat resistive touch
|
| Front Bezel |
- IP65, NEMA 4 rugged protection, plastic front bezel
|
| Power Supply |
- DC version: 12/19 to 24 VDC adapter cable
- AC version: 100 to 240 VAC-DC, 60W power adapter
|
| Power Comsumption |
|
| Watchdog Timer |
|
| Operating Temperature |
- 0°C to +50°C (+32°F to +122°F)
|
| Relative Humidity |
- 20% to 90% @ +40°C; non-condensing
|
| Shock/Vibration |
- 2G, 5 - 500Hz, random for SSD
|
Dimensions
(W x D x H) |
- 259.43 x 43.5 x 232.73 mm (10.21" x 1.71" x 9.16")
|
| Weight (net/gross) |
- 1.8 kg (3.96 lb)/3 kg (6.61 lb)
|
| Certifications |
|
| EOS |
|
| Mounting |
- Panel mount
- Desktop stand
- Wall mount
- VESA arm
|
